Electromagnetism
As defined by Merriam-Webster, electromagnetism is “a magnetic field that is produced by a
current of electricity.”1 This definition is a
little narrow for our discussion.
Thus we must develop a more complete definition of
electromagnetism, the theory of electromagnetism.
In our discussion of electricity and magnetism, we have actually
discussed all the ingredients for a complete theory of
electromagnetism. We
just need to unify the two.
We want to reiterate four facts: an electric field can be created by
charged particles; an electric
field can be created by a changing magnetic field; a magnetic field can be created from a
current; a magnetic field can be
created by a changing electric field.2 Note that one field is
created by the other changing.
By this we can see electricity and magnetism are
intimately related. Now,
what we want is a self-sustaining field.
James Maxwell was
ready to unify electricity and magnetism. “Maxwell was able to
predict that electric and magnetic fields would be able to
sustain themselves, free from charges and currents, if they took
the form of an electromagnetic wave.”3 These waves are a
unification of the electric field
and the magnetic field. The electric and
magnetic field travel perpendicular to one another. They are also a
transverse wave which means they are perpendicular to the
direction they travel in.4 Maxwell combined the
discoveries of the electric and magnetic field to create his
theory of electromagnetism.
Maxwell’s theory of
electromagnetism uses four equations to describe the. When we add the
Lorentz force law the theory of electromagnetism will be
complete. Rather
than just list these equations, a conceptual
description will be offered.
(The formulas
to the right are Maxwell's equations. They are
with respect to the list below.)
Five laws describe the
theory of electromagnetism.
The first four are Maxwell’s equations.
1.
Gauss’s law states that an electric field is created by charged
particles.
2.
Gauss’s law of magnetism states that there are no
isolated magnetic poles.
3.
A changing magnetic field can create an electric
field which is Faraday’s law.
4.
Ampere-Maxwell law
states that electric currents create a
magnetic field and changing electric field can create a
magnetic field.
5.
Lorentz force law says
an electric force is exerted on a
charged particle in an electric field and a magnetic force is exerted on an electric
charge moving in a magnetic field.5
Since we now have a
conceptual understanding of electromagnetism we can look at a
couple of interesting facts
and applications.
