The two most common paces
that we deal with items breaking the sound
barrier are bullets and airplanes.
The bullet to the right shows a good example
of air being pushed from out in front of its
path. The dark line in front of the bullet
and spreading out to the sides is the cone
of dense air. The turbulent air behind the
bullet is the drag from the air trying to
fill the vacuum behind the bullet. We can
calculate the angle that the dense air
shocks that are created with the speed of
the bullet due to the following
relationship.
The sin of the angle is
equal to the velocity of the speed of
sound divided by the velocity of the
object. This shows us that as v becomes
greater then the angle will have to
decrease and become closer and closer to
being parallel with the object.
The other place that we see the sound
barrier being broken is in planes. The
fighter jet on the far right has just
broken the sound barrier and the white
cloud is the shock generated by the dense
air. The speed of such planes is often
categorized as a mach number. The mach
number is the number of times faster then
the speed of sound an object is going
following this relationship.
M is the mach number and c
is the speed of sound. So if your
velocity(v) was twice the speed of sound
we would say you were traveling at mach 2,
a velocity of half the speed of sound
would be mach .5.
